Equipped with advanced adaptive coding and modulation, the IP-100FR2 ensures hitless performance and continuous, real-time link optimization. It’s ideal for fiber extension, enterprise connectivity, and high-availability access links.
PERFECT FOR
- Building-to-building connectivity
- Campus connectivity
- Multi Dwelling Unit (MDU) connectivity
Why Choose IP-100FR2?
+ Ultra-High Capacity — Up to 1 Gbps over the air
+ Hitless Performance — Real-time optimization with advanced adaptive coding and modulation
+ Flexible Deployment — integrated flat-panel antenna for fast installation
+ Future Ready – Remote upgrades with zero-touch rolls
+ Carrier-Grade Reliability – hardened, robust design
TECHNICAL OVERVIEW
| FEATURE | SPECIFICATION |
|---|---|
| Capacity | 1 Gbps over the air |
| Frequency Ranges | 28 GHz TDD and 39 GHz TDD |
| Channel Bandwidth | 100/200/400 MHz |
| Modulation | Up to 1024 QAM |
| Antenna | Integrated Flat Panel Antenna |
| Networking | IEEE 802.1d Transparent Bridging IEEE 802.1ad Provider Bridge IEEE 802.1q Virtual LANs |
| Interfaces | 100MbE, 1 GbE copper (802.3an) with PoE-in |
| Dimensions | 245 mm x 156 mm x 63 mm / 9.65 in x 6.14 in x 2.48 in |
| Weight | 1.8 Kg /3.9 lbs. |
| Operating Temperature | (-45 °C ÷ +55 °C) /49 °F ÷ +131 °F |
| Input Power | 48 VDC PoE or 100-240 VAC |
KEY DIFFERENTIATORS
- Unmatched capacity: 1 Gbps over the air
- Future-ready architecture: with remote upgrades- no truck roll
- Carrier-grade hardened design: for demanding environments
- Versatility Deployment: for building-to-building, campus and enterprise connectivity
